1. Small size, lightweight and relatively compact structure, suitable for installation in ...
Rated Output Torque: 44NM
Fail-stop torque: 88NM
Rated Input Speed: 3000min
Max Input Speed: 6000min
Protect Level: IP65
Max Radial Torque: 850N
Max Axial Torque: 800N
Weight: 2.3kgs
Momentof Inertia: 0.075Kgcm
Full Loading Efficiency: 95%
Lubricating: Synthetic
Installation : Random
Gear ratio: 20-50
Work Temperature: -20+90℃
Logistics Sorting
Automated Robots
laser cutting
Access control gate
Photovoltaic Power Station
Medical Devices
AGV
1. Small size, light weight and relatively compact structure, suitable for installation in the AGV car.
2. High precision, high rigidity.less backlash and large torque, excellent positioning and rotation accuracy
3. Convenient to install, simple to operate, good versatility and long service life.
